Agricultural technology centre

• Base for practice-based teaching – 250 m²
• Approx. 2 km away from the Triesdorf campus
• Facilities and space for student projects
• Electronics, robotics, control, regulation, measuring and testing technology
• Mechanical workshop (sawing, drilling, sheet processing, welding)



Tugs and vehicles:



NCTE torque sensor:

• Measures the torque and rotation speed of the PTO shaft
• Outputs data via analogue signal or CAN bus
• Measures the performance of auxiliary equipment





CAN telemetry system

• Records CAN bus data
• Internal GNSS sensor
• Internal acceleration sensor
• Geocoded collection of CAN data
• Data can be transmitted to server



Tensioning frame

• Used to apply defined loads (forces, moments, deformations) to equipment
• Control using hydraulic bench
• Detection of deformations, stretching, forces
• Metrological proof of strength









Testing tank

• Rotating tank
• Positioning of test specimen, option to attach sensors
• Checking for wear
• Determining the kinematics of multi-body systems
• Representation of soil movement around ploughshares
• Development of prototypes
• Laboratory-scale testing for the preparation of field tests













Hydraulic bench

• 2 kW hydraulic power
• Construction of basic circuits
• Mechanically or electrically controlled, or regulated
• Metrological detection of flow rates and pressures using multi-point measuring system
• For use in teaching and project work
• as a drive unit
